Forward EFP9 Four-Post Lift

Forward Lift’s EFP9 is a light-duty four-post lift that can hold vehicles up to 9,000 pounds. It features a 20-inch runway ideal for wide vehicles and provides 79.25 inches of under-runway clearance to make vehicles easier to service. It’s also ALI- and ETL-certified, ensuring the lift meets industry performance standards.

A blue Rotary SM014 lift holding a black truck

Lift Features

  • Variable Height Locking Positions: The EFP9 has multiple height-locking positions that will make life more comfortable and safe for your technicians. Plus, you can store vehicles at heights that work with your clearance.
  • Adjustable Lock Ladder Leveling System: Even if your shop’s floors are seriously uneven, the EFP9 allows for perfectly level runways at all working heights.
  • Mounting Versatility: The Forward Lift EFP9’s power unit and single-point lock release can be quickly mounted on any of its four commercial-grade columns. You can select which works best in your space.
  • Single-Column Operation: Your operators can safely and quickly operate the EFP9 four-post lift from whichever column you install the power unit on.
  • Durable Steel Approach Ramps: This commercial-grade lift has ultra-tough steel approach ramps with a black powder-coated finish. They’re 30 inches long, making it fast and easy to load low-sitting sports cars.

Forward’s EFP9 four-post lift also includes four drip trays, four heavy-duty polycaster wheels, and a highly durable jack tray.

A red Rotary SM014 lift holding a standard white SUV


  • Capacity: 9,000 lbs
  • Maximum Rise: 84 In.
  • Clearance Under Runway: 79.25 In.
  • Length (With Ramps): 18 Ft. 9.5 In.
  • Length (Without Ramps): 16 Ft. 1.125 In.
  • Width (With Motor): 11.5 Ft.
  • Width (Without Motor): 10 Ft. 1.5 In.
  • Ramp Length: 37 In.
  • Runway Width: 20 In.
  • Runway Length: 184.5 In.
  • Runway Height: 4.75 In.
  • Drive-Thru Width: 97 In.
  • Column Height: 8 Ft. 1 In.
  • Clearance Between Columns: 109.5 In.
  • Clearance Between Runways: 39 In.
  • Motor: 115VAC, 1HP
